Rubber seals Insulated bearings 6318-2RS1/C3VL0241
2015-08-28  |
NINE STAR 6318-2RS1/C3VL0241 Insulated bearings:
| Bearing code number | 6318-2RS1/C3VL0241 |
| Bearing type | Deep groove ball bearing |
| Insulated type | Inner ring or outer ring |
| Demensions | 90x180x43mm |
| d | 90mm |
| D | 190mm |
| B | 43mm |
| Service | Neutral/OEM/As your request |
| Package | Carton boxes /Wooden Cases /Pallets |
| Stock qty | 18pcs |
NINE STAR Insulated bearings suffex
| a) VL0241 Breakdown voltage 1000VDC, Electrical resistance>50MΩ, Outer ring coated
aa) VL2071 Breakdown voltage 1000VDC, Electrical resistance>50MΩ, Inner ring coated b) VL0244 Breakdown voltage 2000VDC, Electrical resistance>150MΩ, Outer ring coated bb) VL2076 Breakdown voltage 2000VDC, Electrical resistance>150MΩ, Inner ring coated c) VL0246 Breakdown voltage 3000VDC, Electrical resistance>150MΩ, Outer ring coated cc) VL0276 Breakdown voltage 3000VDC, Electrical resistance>150MΩ, Inner ring coated |
